| Place of Origin: | China |
|---|---|
| Brand Name: | YAMU |
| Certification: | ISO9001 |
| Model Number: | YM-320V |
| Minimum Order Quantity: | 1PCS |
| Price: | Negotiation |
| Packaging Details: | Wooden Case |
| Delivery Time: | 7days |
| Payment Terms: | T/T |
| Supply Ability: | 10000PCS each month |
| Rated Voltage: | 220V | WORKING SPEED: | 0-850RPM |
|---|---|---|---|
| Core Components: | PLC, Engine, Bearing, Gearbox, Motor, | Name: | Concrete Double Power Trowel |
| Dust Collection Efficiency: | 99% | START MODE: | ELECTRIC START |
| Phase: | 1 Phase | POWER: | 3.7kw |
| High Light: | Double Power Trowel Concrete Floor Grinder,850 RPM Concrete Floor Polishing Machine,300MM Concrete Surface Grinder |
||
Concrete Floor Grinding Polishing Machine 300MM Grinding Width
The Concrete Floor Grinding Machine is the perfect tool for grinding and polishing concrete floors. This machine is a 3 Phase, 220V, Toshiba Japan Motor Type Concrete Double Power Trowel. It is available in a range of colors, including Orange, White, and Red. It is the perfect choice for grinding and polishing all types of concrete floors, from driveways to garages, warehouses to industrial plants. This Floor Driving Grinding Machine is designed to provide superior performance in both grinding and polishing, making it the ideal choice for concrete floor grinding and polishing. It is easy to use and highly efficient, giving you the perfect finish every time. This Concrete Floor Grinding polishing Machine is a must-have for anyone looking to achieve a professional and long-lasting finish on any concrete floor.
| Mode | YM-320B | YM-320D | YM-320E | YM-320V |
| Work Diameter | 320mm | 320mm | 320mm | 320mm |
| Voltage | 380v | 380v | 380v | 220v |
| Phase | 3 phase | 3 phase | 3 phase | 1 phase |
| Power | 3.7KW (5Hp) | 3.7KW (5Hp) | 3.7KW (5Hp) | 3.7KW (5Hp) |
| Frequency Converter | 3.7KW (5Hp) | |||
| Disc Quantity | 3 | 3 | 3 | 3 |
| Rotating Speed | 0-720rpm | 0-720rpm | 0-720rpm | 0-720rpm |
| Rated voltage(cleaner) | 220V * 5A | 220V * 5A | 220V * 5A | 220V * 5A |
| Output power | 1KW | 1KW | 1KW | 1KW |
| Maximum air volume | 3M ³/ min | 3M ³/ min | 3M ³/ min | 3M ³/ min |
| Dust collection capacity | 19L | 19L | 19L | 19L |
| Weight | 120kg | 120kg | 120kg | 120kg |
| Length * width * height (mm) | 1200 * 400 * 896 | 1200 * 400 * 896 | 1200 * 400 * 896 | 1200 * 400 * 896 |
| MOTOR TYPE | Toshiba Japan | Toshiba Japan | Toshiba Japan | Toshiba Japan |
| Power line length (m) | 20M (2mm ²* 4cores) | |||
| Machine type | Terrazzo Marble Epoxy Stone concrete Floor Grinders | |||
YAMU YM-320V is a hand push semi-automatic concrete grinding machine with powerful Toshiba motor and dust collection efficiency of 99%. It is suitable for grinding and polishing terrazzo, marble, epoxy, stone, and other concrete surfaces. The machine is certified with ISO9001 and comes in color options of orange, white and red. It has a length of power cord of 20m (2.5mm²*4core) and the minimum order quantity is 1PCS. The machine is packaged in wooden case and delivery time is 7 days. The supply ability of this machine is 10,000PCS each month and the price is negotiable with payment terms of T/T.
Concrete Floor Grinding Machine Technical Support and Service
